ASUS TUF Gaming FA507RM-HN091W RAM upgrade specifications
ASUS TUF Gaming A15 FA507RM-HN091W RAM upgrade specifications include DDR5-SDRAM memory compatible with 2x SO-DIMM slots. The laptop supports maximum RAM capacity of 32 GB total, operating at 4800 MHz frequency. Memory upgrades utilize SO-DIMM form factor modules. Compatible DDR5-SDRAM modules can be installed in either slot to expand the system's memory capacity for enhanced multitasking and performance capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 04 October 2022 |
Additional Notes
- Dual channel memory architecture is achievable on the ASUS TUF Gaming FA507RM-HN091W by populating both slots with identical modules to increase memory bandwidth for CPU intensive tasks.
- The absence of soldered memory on the motherboard ensures that the entire system memory remains serviceable and replaceable if a module fails.
- Installing modules with higher clock speeds than 4800 MHz will result in downclocking to the platform limit dictated by the integrated memory controller.
- Upgrading to the maximum 32 GB capacity requires the removal of existing modules because the system lacks vacant expansion slots.
- Standard voltage DDR5 SO DIMM modules are required to ensure stability since the motherboard firmware does not support XMP or manual voltage adjustments for overclocking.
- Low latency performance is contingent on the use of 1Rx8 or 2Rx8 rank configurations as high density 1Rx16 modules can introduce bottlenecks in gaming frame rates.
- The physical installation process necessitates a grounded workspace to prevent electrostatic discharge damage to the sensitive DDR5 circuit architecture.
