ASUS TUF Gaming FA507UI-HQ010W RAM upgrade specifications
ASUS TUF Gaming A15 FA507UI-HQ010W features DDR5-SDRAM memory upgrade specifications. Laptop includes two SO-DIMM slots supporting maximum RAM capacity of 32 GB. Compatible memory operates at 5600 MHz frequency. SO-DIMM form factor specifies memory upgrade requirements. Upgrade slots accommodate DDR5 modules to enhance system performance and multitasking capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 5600 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-5600 (PC5-44800) |
| Bandwidth | 44.8 GB/s |
Additional Notes
- Dual channel architecture requires matching module pairs to achieve full memory bandwidth and prevent latency variances.
- The hardware architecture of the ASUS TUF Gaming FA507UI-HQ010W limits total addressable memory to 32 GB regardless of higher capacity modules availability in the market.
- Physical installation necessitates standard 262 pin modules due to the small outline dual in line memory module configuration.
- Operating at the specified frequency depends on the integrated memory controller maintaining stability across both occupied slots.
- The absence of soldered memory allows for the replacement of both factory modules to facilitate symmetric performance scaling.
- Upgrades utilizing modules with higher rated speeds will result in downclocking to the system firmware limits.
- Accessing the internal slots for installation requires removing the bottom chassis panel and disconnecting the internal power source to prevent electrostatic discharge damage.
