ASUS TUF Gaming FA507XI-LP013W RAM upgrade specifications
The ASUS TUF Gaming A15 FA507XI-LP013W features DDR5-SDRAM memory upgrade specifications with 2x SO-DIMM slots supporting maximum capacity of 32 GB. Compatible RAM operates at 4800 MHz frequency using SO-DIMM form factor. Upgrade specifications indicate support for dual-channel memory configuration, enabling enhanced performance through expanded memory capacity on this gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
Additional Notes
- The presence of 2 SO-DIMM slots confirms a dual-channel architecture which requires paired modules to maximize memory bandwidth for the AMD Ryzen processor.
- The 32 GB ceiling indicates a firmware or density limitation that prevents the use of 32 GB single-stick modules for a 64 GB total configuration.
- Installing memory with frequencies higher than 4800 MHz will result in automatic downclocking to match the system bus speed defined by the ASUS TUF Gaming FA507XI-LP013W motherboard.
- Upgrading the pre-installed memory requires the complete removal of existing modules if both slots are occupied from the factory.
- The DDR5 standard operates at a lower base voltage than DDR4 which reduces thermal pressure on the motherboard during high-load gaming or rendering tasks.
- Latency timings are locked by the BIOS preventing manual adjustments to the CAS latency after installing aftermarket kits.
- Physical access to the memory slots necessitates the removal of the entire lower chassis panel which may involve various screw lengths and plastic clips.
