ASUS TUF Gaming FA617NS-N3002W RAM upgrade specifications
ASUS TUF Gaming A16 Advantage Edition FA617NS-N3002W laptop features two SO-DIMM slots supporting DDR5-SDRAM memory upgrade specifications. Maximum RAM capacity reaches 32 GB with compatible modules operating at 4800 MHz frequency. Current memory configuration and available upgrade slots enable expansion of system memory to achieve maximum specifications. Specifications indicate SO-DIMM form factor compatibility for memory module installation and upgrade procedures.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
Additional Notes
- Dual channel mode requires identical module capacities and timings across both slots to prevent the system from defaulting to single channel bandwidth.
- The 32 GB ceiling necessitates replacing existing modules if the laptop is currently configured with two lower capacity sticks because no vacant slots remain for expansion.
- Operating at 4800 MHz on the DDR5 platform reduces power consumption while providing higher burst rates compared to legacy DDR4 architecture.
- The ASUS TUF Gaming FA617NS-N3002W utilizes standard SO-DIMM sockets which allow for manual hardware replacement without specialized soldering tools.
- Installing memory modules with higher frequency ratings will result in downclocking to the system maximum of 4800 MHz due to firmware limitations.
- Accessing the memory slots requires removal of the bottom chassis panel which may involve various screw lengths and plastic clips sensitive to mechanical stress.
- The integrated memory controller architecture minimizes latency by placing the DRAM in close physical proximity to the processor socket.
