ASUS TUF Gaming FA617NS-N3003W RAM upgrade specifications
The ASUS TUF Gaming A16 Advantage Edition FA617NS-N3003W features DDR5-SDRAM memory upgrade specifications. The laptop contains two SO-DIMM slots with a maximum RAM capacity of 32 GB. Compatible memory modules operate at 4800 MHz frequency. Current memory configuration and available upgrade options depend on the factory-installed specifications. Users seeking to upgrade RAM should verify compatibility with ASUS-approved DDR5 memory modules meeting SO-DIMM form factor requirements. Maximum supported memory capacity across both slots is limited to 32 GB total.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
Additional Notes
- The dual channel architecture requires symmetrical module pairs to achieve maximum memory bandwidth for the integrated graphics and CPU communication.
- The Asus TUF Gaming FA617NS-N3003W utilizes a non soldered memory configuration that allows for total replacement of factory modules if the 32 GB threshold is reached.
- The 4800 MHz frequency indicates a baseline DDR5 performance level where installing higher speed modules will result in downclocking to match the system firmware limits.
- Physical installation entails accessing the internal chassis which requires a Phillips head screwdriver and a plastic prying tool to avoid damaging the bottom panel clips.
- Upgrading to the maximum supported capacity ensures sufficient overhead for modern gaming workloads and background streaming applications without relying on slower virtual memory page files.
