ASUS TUF Gaming FA617XS-N3037W RAM upgrade specifications
ASUS TUF Gaming A16 Advantage Edition FA617XS-N3037W laptop features two SO-DIMM slots supporting DDR5-SDRAM memory upgrade specifications. The maximum RAM capacity reaches 32 GB total, with compatible memory operating at 4800 MHz frequency. Upgrade configurations allow installation of DDR5 modules in both available slots to achieve maximum specifications for enhanced system performance and multitasking capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
Additional Notes
- The presence of 2 SO-DIMM slots allows for a dual-channel memory configuration which improves data throughput and reduces latency compared to single-channel setups.
- The maximum supported capacity of 32 GB suggests a hardware limitation in the motherboard firmware or the processor memory controller regarding total addressable banks.
- Utilizing DDR5-SDRAM at 4800 MHz requires modules that support the JEDEC standard to ensure stability without manual BIOS adjustments.
- Physical access to the internal memory modules in the ASUS TUF Gaming FA617XS-N3037W involves removing the bottom chassis panel which may expose the internal battery and cooling assembly to static discharge risks.
- Installing modules with higher rated frequencies will result in automatic downclocking to the system maximum of 4800 MHz due to chipset restrictions.
- The 32 GB limit necessitates the replacement of both existing modules if the factory configuration occupies both slots and a capacity increase is desired.
- Mixing modules from different manufacturers or with different timings can trigger stability issues or force the system into a lower performance state.
