ASUS TUF Gaming FA707NU-DS74 RAM upgrade specifications
The ASUS TUF Gaming A17 FA707NU-DS74 features DDR5-SDRAM memory upgrade specifications with 2 SO-DIMM slots supporting maximum RAM capacity of 24 GB. Compatible memory modules operate at 4800 MHz frequency with SO-DIMM form factor. Upgrade slots accommodate DDR5 memory to enhance system performance. Specifications indicate total expandable memory capacity reaches 24 GB configuration for the FA707NU-DS74 model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 24 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 10 February 2023 |
Additional Notes
- The presence of 2 SO-DIMM slots confirms that the system maintains a dual-channel memory architecture which is essential for maximizing the processing bandwidth of the ASUS TUF Gaming FA707NU-DS74 hardware.
- A maximum capacity of 24 GB necessitates an asymmetrical memory configuration where a 16 GB module and an 8 GB module are paired together.
- Asymmetrical RAM configurations result in the system operating in Flex Mode where dual-channel speeds only apply to the first 16 GB of memory and the remaining 8 GB operates at single-channel speeds.
- The 4800 MHz frequency reflects the base operational speed of the DDR5 standard and will automatically downclock any higher-rated modules to match this hardware-locked ceiling.
- Installation of memory requires the removal of the bottom chassis panel which exposes internal components to potential electrostatic discharge risks during the upgrade process.
- The use of DDR5 technology indicates a 262-pin physical interface which is incompatible with older DDR4 SO-DIMM modules due to different voltage requirements and key notch positions.
- Total memory bandwidth is limited by the integrated controller within the processor which dictates the maximum stable transfer rate regardless of the theoretical speed of aftermarket kits.
