ASUS TUF Gaming FA707NV-HX052W RAM upgrade specifications

ASUS FA707NV-HX052W ASUS FA707NV-HX052W ASUS FA707NV-HX052W ASUS FA707NV-HX052W ASUS FA707NV-HX052W

The ASUS TUF Gaming A17 FA707NV-HX052W features DDR5-SDRAM memory upgradeable through two SO-DIMM slots. Maximum RAM capacity reaches 32 GB total, operating at 4800 MHz frequency. Compatible memory modules must utilize the SO-DIMM form factor for proper installation in the upgrade slots. Specifications support DDR5 technology for enhanced bandwidth and performance characteristics in the TUF Gaming series laptop model.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR5-SDRAM
Frequency4800 MHz
Maximum RAM32 GB
Voltage1.1V
Number of pins262-pin
InterfacePC5
PC Speed RatingPC5-4800 (PC5-38400)
Bandwidth38.4 GB/s

Additional Notes

  • The presence of 2 physical SO-DIMM slots implies that existing factory modules must be removed and replaced rather than supplemented to reach the maximum 32 GB threshold.
  • Operating the ASUS TUF Gaming FA707NV-HX052W with unmatched memory modules will disable dual-channel architecture and significantly reduce bandwidth for the integrated graphics processor.
  • Installing memory with frequencies higher than 4800 MHz will result in automatic downclocking to match the internal controller constraints of the motherboard chipset.
  • The transition to the DDR5 standard utilizes on-module Power Management Integrated Circuits which increases heat dissipation requirements compared to older DDR4 hardware.
  • Physical access to the memory slots requires the removal of the entire bottom chassis covering which may involve hidden clips and varying screw lengths.
  • The 32 GB maximum capacity prevents the use of 32 GB single-stick configurations or 64 GB kits regardless of physical slot compatibility.
  • Internal memory layout utilizes standard 262-pin connectors which are incompatible with 260-pin DDR4 modules despite similar physical lengths.
