ASUS TUF Gaming FA707RM-HX005W RAM upgrade specifications
ASUS TUF Gaming A17 FA707RM-HX005W laptop features DDR5-SDRAM memory upgrade capability. The system includes 2x SO-DIMM slots supporting maximum capacity of 32 GB total. Compatible RAM operates at 4800 MHz frequency with SO-DIMM form factor. Specifications enable memory expansion for enhanced multitasking performance and gaming applications on this TUF Gaming series mobile workstation.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 12 August 2022 |
Additional Notes
- Dual channel memory architecture requires populated pairs of identical modules to achieve peak memory bandwidth and prevent CPU performance bottlenecks during heavy gaming or rendering tasks.
- The 32 GB capacity ceiling dictates that 16 GB modules are the largest supported individual sticks for this hardware configuration.
- Lower latency DDR5 modules will automatically downclock to the 4800 MHz motherboard limit established by the Ryzen chipset architecture within the ASUS TUF Gaming FA707RM-HX005W.
- The absence of soldered memory on the motherboard facilitates total replacement of the factory RAM without being limited by fixed onboard components.
- Physical installation requires standard 262 pin DDR5 SO-DIMM hardware as older 260 pin DDR4 modules are physically incompatible due to unique notch positioning.
- Operating beyond the specified 32 GB total may result in system instability or failure to post because the BIOS firmware does not officially recognize higher density memory sticks.
