ASUS TUF Gaming FA707RE-HX030W RAM upgrade specifications
The ASUS TUF Gaming A17 FA707RE-HX030W features DDR5-SDRAM memory upgrade specifications with two SO-DIMM slots supporting a maximum RAM capacity of 32 GB. Compatible memory operates at 4800 MHz frequency. The laptop specifications include DDR5 memory slots for upgrade configurations, accommodating standard SO-DIMM form factor modules. Maximum memory capacity reaches 32 GB through dual slot configuration, enabling users to expand from factory-installed capacity. The TUF Gaming A17 FA707RE-HX030W supports high-frequency DDR5 memory upgrades at 4800 MHz specifications.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 19 January 2022 |
Additional Notes
- The ASUS TUF Gaming FA707RE-HX030W employs a 2-slot SO-DIMM configuration, meaning the entire memory subsystem is accessible without disassembling the display panel or removing the motherboard, facilitating field upgrades within typical warranty parameters.
- DDR5-4800 memory operates at significantly higher latency cycles per clock compared to DDR4 equivalents, requiring compatible BIOS versions to achieve rated speeds; systems shipped with older firmware may default to DDR5-4400 or lower, reducing effective bandwidth until updated.
- The 32 GB aggregate ceiling represents a constraint for workloads exceeding this threshold, such as virtualization environments or professional rendering tasks; single-channel memory configurations would occur if only 1 SO-DIMM is populated, halving memory bandwidth and creating asymmetric performance penalties in multi-threaded applications.
- SO-DIMM modules occupy less vertical clearance than standard DIMM form factors, but the 2-slot design leaves no expansion capacity once the 32 GB maximum is reached, requiring complete module replacement rather than additive upgrades for future memory scaling.
- DDR5-4800 specification assumes compliance with JEDEC DDR5 standards; third-party modules rated for 6000 MHz or higher may operate outside manufacturer validation ranges, potentially triggering stability issues or voiding coverage if return merchandise authorization processes detect non-standard memory installations.
