ASUS TUF Gaming FA707RW-HX003W RAM upgrade specifications
ASUS TUF Gaming A17 FA707RW-HX003W laptop features DDR5-SDRAM memory upgrade specifications. The system contains 2x SO-DIMM slots supporting maximum RAM capacity of 32 GB. Compatible memory modules operate at 4800 MHz frequency. Upgrade options accommodate DDR5-SDRAM SO-DIMM form factor specifications for enhanced performance on the FA707RW-HX003W model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 17 February 2022 |
Additional Notes
- The ASUS TUF Gaming FA707RW-HX003W supports DDR5 memory at 4800 MHz, which requires compatible DDR5-capable SO-DIMM modules. DDR4 memory is not interchangeable with this slot configuration and will not function if installed.
- With 2 SO-DIMM slots and a 32 GB maximum capacity ceiling, the unit supports configurations of 16 GB plus 16 GB as the highest single-module upgrade path. Asymmetrical pairing (such as 8 GB plus 16 GB) remains functional but forces the memory controller to operate in single-channel mode on the mismatched capacity, reducing effective bandwidth by approximately 50 percent.
- DDR5-4800 MHz specification indicates the memory operates at JEDEC standard speeds rather than overclocked profiles. This constraint means third-party DDR5 modules rated at 5200 MHz, 5600 MHz, or higher will downclock automatically to 4800 MHz unless BIOS overclocking is enabled, negating performance advantages of premium-tier modules.
- SO-DIMM slot access typically requires removal of bottom panel components on this gaming chassis. Technicians must verify thermal paste proximity to the SO-DIMM area before installation, as adhesive thermal compounds on nearby components may harden and crack during memory module insertion or removal operations.
- Upgrading beyond the factory configuration voids certain manufacturer memory-related warranties on some ASUS TUF configurations. Confirmation of specific warranty terms for the FA707RW-HX003W model is required before purchasing third-party DDR5 modules, as ASUS may restrict coverage to only factory-installed memory during the initial service period.
