ASUS TUF Gaming FA808UP-S8072W RAM upgrade specifications

ASUS FA808UP-S8072W ASUS FA808UP-S8072W ASUS FA808UP-S8072W ASUS FA808UP-S8072W ASUS FA808UP-S8072W

ASUS TUF Gaming A18 FA808UP-S8072W laptop features DDR5-SDRAM memory upgrade capability. The system includes 2x SO-DIMM slots supporting maximum RAM capacity of 64 GB. Compatible memory modules operate at 5600 MHz frequency with SO-DIMM form factor. Specifications enable significant memory expansion for enhanced multitasking and performance optimization in gaming and professional applications.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR5-SDRAM
Frequency5600 MHz
Maximum RAM64 GB
Voltage1.1V
Number of pins262-pin
InterfacePC5
PC Speed RatingPC5-5600 (PC5-44800)
Bandwidth44.8 GB/s

Additional Notes

  • The presence of 2 discrete SO-DIMM slots confirms that memory is not soldered to the motherboard, allowing for the complete replacement of factory modules to reach the 64 GB threshold.
  • Utilizing a matched pair of modules in the ASUS TUF Gaming FA808UP-S8072W is necessary to enable dual-channel interleaving, which significantly increases memory bandwidth for CPU-intensive tasks.
  • The 5600 MHz clock speed indicates a high-performance DDR5 bus which requires modules with compatible Serial Presence Detect profiles to avoid downclocking to base JEDEC speeds.
  • Operating at the maximum supported 64 GB capacity provides the necessary headroom for complex 3D rendering and virtual machine hosting without relying on slower disk-based swap files.
  • Physical installation of new hardware requires the removal of the chassis base plate, making it essential to use non-conductive tools to prevent electrostatic discharge to the internal circuitry.
  • The system architecture relies on low-voltage DDR5 standards, meaning older DDR4 modules are physically and electrically incompatible due to different notch positions and voltage requirements.
