ASUS TUF Gaming FX506HC-HN004W RAM upgrade specifications
ASUS TUF Gaming F15 FX506HC-HN004W laptop features DDR4-SDRAM memory with two SO-DIMM slots supporting maximum RAM capacity of 32 GB. Specifications indicate compatible memory operates at 3200 MHz frequency. Upgrade slots accommodate SO-DIMM form factor modules. Specifications confirm maximum memory configuration of 32 GB total capacity for this FX506HC-HN004W model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 19 February 2022 |
Additional Notes
- Dual channel architecture requires matching memory modules across both SO-DIMM slots to optimize memory bandwidth and reduce system latency.
- The maximum capacity limit of 32 GB dictates that the ASUS FX506HC-HN004W can only support a maximum of 16 GB per individual slot.
- Installing modules with higher clock speeds results in downclocking to 3200 MHz to maintain stability with the integrated memory controller.
- Upgrading to non-ECC unbuffered memory is mandatory as the hardware does not support error correction protocols.
- Accessing the internal slots for expansion requires the removal of the bottom chassis panel which may involve breaking factory tamper seals depending on regional warranty policies.
- Physical clearance within the motherboard housing restricts upgrades to standard height SO-DIMM modules and prevents the use of those equipped with oversized heat spreaders.
- Mixing modules from different manufacturers or with differing CAS latencies causes the system to default to the slowest common denominator timings.
