ASUS TUF Gaming FX506HE-HN315W RAM upgrade specifications
ASUS TUF Gaming F15 series model FX506HE-HN315W supports DDR4-SDRAM memory upgrades. The laptop contains 2x SO-DIMM slots for RAM expansion, with maximum compatible capacity of 32 GB total. Memory specifications include DDR4 technology operating at 3200 MHz frequency. SO-DIMM form factor modules are required for upgrade compatibility. Current memory configuration and available slot capacity determine upgrade options for this gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 25 May 2022 |
Additional Notes
- Dual channel mode requires identical module pairs across both slots to maximize memory bandwidth for the ASUS TUF Gaming FX506HE-HN315W.
- The absence of soldered memory allows for the replacement of both factory modules to reach the maximum threshold without being limited by fixed onboard components.
- Installing modules with frequencies higher than 3200 MHz will result in automatic downclocking to match the integrated memory controller limits.
- System stability depends on using non-ECC unbuffered modules because the architecture does not support error correction code memory.
- Accessing the SO-DIMM slots requires the removal of the entire base plate which may involve navigating different screw lengths to avoid chassis damage.
- Physical clearance within the motherboard area restricts upgrades to standard height SO-DIMM modules and precludes the use of thick aftermarket heat spreaders.
- Achieving 32 GB of total capacity requires 2 16 GB modules as there is no support for single 32 GB density sticks in this specific hardware configuration.
