ASUS TUF Gaming FX506HM-HN178R RAM upgrade specifications
The ASUS TUF Gaming F15 FX506HM-HN178R laptop features DDR4-SDRAM memory upgrade capability through two SO-DIMM slots. Maximum RAM capacity reaches 32 GB total, with compatible modules operating at 3200 MHz frequency. Specifications allow for memory expansion using standard SO-DIMM form factor DDR4 memory modules. Current memory configuration supports upgrade paths to boost system RAM capacity for enhanced multitasking and application performance.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 10 December 2021 |
Additional Notes
- Dual channel memory architecture requires installing 2 matched modules to maximize memory bandwidth for the processor and integrated graphics.
- The absence of soldered memory on the ASUS TUF Gaming FX506HM-HN178R motherboard allows for the total replacement of factory modules to reach the maximum supported capacity.
- Mixing modules with different latency timings will force the system to operate at the slowest common denominator, potentially causing performance stability issues.
- Upgrading beyond the 32 GB threshold exceeds the verified addressable space of the firmware and will likely lead to boot failure or system instability.
- The physical SO-DIMM interface necessitates 260-pin modules, as larger desktop DIMM components are electrically and mechanically incompatible.
- Operating at 3200 MHz requires modules that support JEDEC standard profiles to ensure the speed is achieved without manual BIOS voltage adjustments.
- Internal access for memory replacement requires the removal of the bottom chassis panel, which involves managing captive screws to avoid hardware loss.
