ASUS TUF Gaming PX707ZM-HX071X RAM upgrade specifications
The ASUS TUF Gaming F17 series PX707ZM-HX071X laptop features DDR5-SDRAM memory upgrade specifications with two SO-DIMM slots supporting maximum capacity of 32 GB RAM. Compatible memory modules operate at 4800 MHz frequency. Upgrade specifications are available for the TUF Gaming F17 series model, detailing memory slots, capacity specifications, and RAM compatibility requirements for this ASUS PX707ZM-HX071X configuration.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 25 July 2022 |
Additional Notes
- Dual channel memory architecture is required to maximize the integrated memory controller bandwidth during high intensity tasks.
- The 32 GB capacity ceiling restricts the ASUS PX707ZM-HX071X from utilizing 32 GB or 48 GB single modules commonly found in newer generation DDR5 kits.
- Installing modules with higher clock speeds results in automatic downclocking to the 4800 MHz platform limit set by the system firmware.
- Physical access to the SO-DIMM slots typically necessitates the removal of the entire bottom chassis panel which may involve various screw lengths.
- Populating both slots with identical capacity and timing specifications ensures stable operation and prevents performance drops associated with asynchronous memory configurations.
- Higher latency modules can create data processing bottlenecks despite the high raw frequency of the DDR5 standard.
- The use of SODIMM form factor modules precludes the installation of desktop DIMM hardware or soldered LPDDR5 alternatives.
