ASUS Vivobook X412DA-EK181T RAM upgrade specifications
The ASUS Vivobook 14 Series X412DA-EK181T features DDR4-SDRAM memory with upgrade capabilities through a single SO-DIMM slot. The laptop contains onboard memory paired with one accessible SO-DIMM slot, supporting a maximum RAM capacity of 12 GB. Memory specifications include DDR4 operation at 2400 MHz frequency. The RAM upgrade configuration provides expandable memory slots for compatible DDR4 modules, allowing users to enhance system performance through additional memory installation within the specified maximum capacity constraints.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 12 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 07 June 2019 |
Additional Notes
- The ASUS Vivobook X412DA-EK181T contains soldered memory on the motherboard, meaning only the single SO-DIMM slot is user-accessible for upgrades, limiting total expansion to 12 GB rather than the theoretical capacity of dual slots.
- DDR4-2400 MHz operates at a lower frequency tier than mainstream DDR4-3200 modules, creating potential compatibility issues if higher-frequency SO-DIMM modules are installed, as the controller will downclock them to 2400 MHz or reject them entirely depending on BIOS implementation.
- Upgrading the SO-DIMM slot to the 12 GB maximum requires a single 8 GB module, as the on-board soldered portion occupies the remaining 4 GB allocation within the 12 GB ceiling.
- SO-DIMM form factor availability at 2400 MHz is limited in the current market, as DDR4-2400 SO-DIMM modules are becoming obsolete in favor of DDR4-3200 and DDR5 variants, potentially increasing search time and cost for warranty-compliant replacements.
- The single memory slot configuration creates a performance ceiling that cannot be overcome through parallelization, meaning memory-intensive multitasking workflows cannot benefit from dual-channel bandwidth optimization even after maximum upgrade.
- Installation of any SO-DIMM module requires physical access to the battery and potentially partial disassembly of the chassis; verification of warranty policies before opening the device is necessary to avoid voiding manufacturer coverage.
