ASUS Vivobook F512DA-EB55-CL RAM upgrade specifications
The ASUS Vivobook 15 Series F512DA-EB55-CL laptop features DDR4-SDRAM memory configuration with one SO-DIMM slot available for upgrade. The system contains 1x SO-DIMM memory slot compatible with DDR4-SDRAM modules operating at 2400 MHz frequency. Maximum supported RAM capacity reaches 12 GB when the SO-DIMM slot is populated. Memory upgrade specifications indicate on-board memory combined with single SO-DIMM slot configuration. Compatible DDR4-SDRAM memory upgrades enable increased system memory capacity for enhanced multitasking performance on the Vivobook 15 model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 12 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 27 May 2019 |
Additional Notes
- The ASUS Vivobook F512DA-EB55-CL contains soldered on-board memory that cannot be removed, limiting practical upgrade capacity to the single SO-DIMM slot available.
- Maximum addressable memory of 12 GB indicates 4 GB of non-removable on-board RAM paired with a single 8 GB SO-DIMM slot, establishing a hard ceiling on total system memory regardless of future DDR4 module availability.
- DDR4-2400 MHz specification means replacement modules must match this exact frequency; installing faster DDR4 variants (2666, 3000, 3200 MHz) will downclock to 2400 MHz, negating any speed advantage and consuming warranty consideration.
- Single SO-DIMM architecture creates a single point of failure for user-upgradeable memory; if the slot develops contact issues or the module fails, the system reverts to 4 GB operational capacity.
- The soldered memory design eliminates conventional dual-channel configuration options; all installed RAM operates in single-channel mode, reducing memory bandwidth efficiency compared to systems with 2 populated slots.
- SO-DIMM modules rated for 2400 MHz have become less common in retail markets as manufacturers shifted production to faster variants, potentially limiting replacement options without extending lead times.
- Upgrading to 8 GB SO-DIMM does not require BIOS modification or firmware updates, making the installation process straightforward and maintaining factory warranty compliance if performed without disassembling sealed components.
