ASUS Vivobook X512UA-EJ141T RAM upgrade specifications
ASUS Vivobook 15 Series X512UA-EJ141T RAM upgrade specifications indicate one SO-DIMM slot for memory expansion. Laptop features DDR4-SDRAM memory operating at 2400 MHz frequency. Maximum RAM capacity reaches 12 GB total, combining on-board memory with upgradeable SO-DIMM slot. Compatible memory upgrades utilize DDR4 standard for Vivobook 15 X512UA-EJ141T model specifications.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 12 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 04 August 2019 |
Additional Notes
- The ASUS Vivobook X512UA-EJ141T contains soldered on-board memory, meaning a portion of the 12 GB maximum capacity cannot be physically removed or replaced. Only the single SO-DIMM slot permits user-accessible upgrades.
- Upgrading to the 12 GB ceiling requires installing a 8 GB SO-DIMM module in the available slot, as the on-board component is non-replaceable. This asymmetrical configuration creates mixed-density memory architecture.
- The 2400 MHz specification represents a legacy DDR4 speed tier. Sourcing replacement or upgrade modules at this exact frequency may prove difficult in contemporary markets, where DDR4-3200 and faster variants dominate retail availability.
- Installing an SO-DIMM module rated for higher frequencies (3200 MHz or above) will downclock to match the 2400 MHz system speed, resulting in no performance gain but full operational compatibility through JEDEC specification adherence.
- The single SO-DIMM slot eliminates future expandability beyond 12 GB. No upgrade path exists beyond populating this one slot with the maximum-capacity module the firmware and chipset support.
- Warranty implications apply when accessing the SO-DIMM compartment. ASUS service documentation should be consulted to confirm whether memory installation is user-serviceable without voiding coverage.
