ASUS Vivobook TP412FA-EC079T-BE RAM upgrade specifications
ASUS Vivobook Flip TP412FA-EC079T-BE laptop contains DDR4-SDRAM memory upgrade capacity. The device features one SO-DIMM slot for RAM expansion, supporting maximum memory capacity of 12 GB total. Memory specifications include 2400 MHz frequency operation. Upgrade configuration combines on-board memory with one replaceable SO-DIMM module. Compatible DDR4 memory modules can be installed in the available slot to enhance system performance and multitasking capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 12 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 06 August 2019 |
Additional Notes
- The presence of a single SO-DIMM slot alongside soldered memory indicates that the ASUS Vivobook TP412FA-EC079T-BE operates in an asymmetrical dual-channel configuration when the expansion slot is populated.
- Upgrading the removable module to a higher frequency than 2400 MHz results in automatic downclocking to match the fixed speed of the integrated system memory chips.
- The 12 GB limit suggests the system utilizes 4 GB of non-removable RAM, restricting the expansion slot to an 8 GB module for stable operation.
- Replacing the existing SO-DIMM requires access to the internal motherboard since the chassis lacks a dedicated external service hatch for memory components.
- Memory latency and bandwidth performance are constrained by the slowest module installed, meaning mismatched timings between the on-board chips and the upgrade stick will default to the least aggressive profile.
- Total system memory capacity is non-expandable beyond the stated threshold because the motherboard firmware lacks support for 16 GB or 32 GB modules in the available slot.
