DELL Inspiron 7548 RAM upgrade specifications

DELL 7548 DELL 7548 DELL 7548 DELL 7548 DELL 7548

The DELL Inspiron 7000 Series 7548 laptop features DDR3L-SDRAM memory upgrade specifications with 2x SO-DIMM slots supporting a maximum RAM capacity of 16 GB. Compatible memory modules operate at 1600 MHz frequency in SO-DIMM form factor. Upgrade options allow users to expand the existing memory configuration up to the maximum specified capacity of 16 GB total. Memory specifications define compatible DDR3L-SDRAM modules for this DELL Inspiron 7548 model.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR3L-SDRAM
Frequency1600 MHz
Maximum RAM16 GB
Voltage1.35V (Low Voltage)
Number of pins204-pin
InterfacePC3L
PC Speed RatingPC3L-1600 (PC3L-12800)
Bandwidth12.8 GB/s
Laptop Release date13 January 2016

Additional Notes

  • The specified memory standard operates at 1.35 volts, meaning standard DDR3 modules running at 1.5 volts will likely cause system instability or failure to boot.
  • The dual slot configuration allows for a symmetrical dual-channel memory architecture which doubles the available bandwidth for integrated graphics processing on the DELL Inspiron 7548.
  • Upgrading to the maximum capacity requires the removal of existing modules because the motherboard lacks additional vacant expansion headers.
  • High density 16 GB single modules are incompatible due to the 8 GB per slot hardware addressing limit of the processor generation.
  • Installing memory with higher clock speeds will result in downclocking to the motherboard bus limit, providing no performance gain over the native frequency.
  • Accessing the SO-DIMM slots necessitates the removal of the entire base panel, which may require specialized prying tools to avoid damaging plastic clips.
  • The utilization of SO-DIMM 204-pin architecture prevents the use of newer DDR4 or desktop-class DIMM hardware.
