HP Elitebook 845 G10 RAM upgrade specifications
HP Elitebook 845 G10 RAM upgrade specifications include DDR5-SDRAM memory compatible with 2x SO-DIMM slots. Maximum capacity reaches 64 GB total memory. Upgrade specifications support DDR5-5600 MHz frequency standard. SO-DIMM form factor ensures compatibility with this Elitebook series model. Memory slots accommodate individual modules up to 32 GB per slot for maximum configuration.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 5600 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-5600 (PC5-44800) |
| Bandwidth | 44.8 GB/s |
| Laptop Release date | 28 August 2023 |
Additional Notes
- The presence of 2 dedicated SO-DIMM slots in the HP Elitebook 845 G10 confirms that memory is not soldered to the mainboard, allowing for dual-channel symmetric bandwidth configurations.
- Upgrading to the 64 GB maximum capacity requires the removal of existing modules if both slots are occupied from the factory.
- The system architecture supports high-speed DDR5 sync rates which reduces latency for integrated graphics processing compared to older DDR4 standards.
- Mixing modules with different rated frequencies results in the system downclocking all memory to the lowest common denominator speed.
- Physical installation of memory does not require proprietary tools, but internal access typically involves non-retained screws and internal plastic clips.
- The utilization of 2 matching capacity modules is necessary to enable 128-bit memory bus operation for optimal thermal and power efficiency.
- Potential BIOS limitations may require a firmware update to recognize high-density 32 GB modules if they were released after the initial hardware manufacture date.
