HP Stream 11 Pro G5 RAM upgrade specifications
HP Stream 11 Pro G5 RAM upgrade specifications detail memory expansion options for the laptop model. The device features 1x SO-DIMM slot for DDR4-SDRAM memory modules operating at 2400 MHz frequency. Maximum compatible RAM capacity reaches 4 GB. Upgrade specifications indicate SO-DIMM form factor compatibility for memory installation. RAM upgrade specifications for HP Stream 11 Pro G5 provide information on memory slot availability, maximum capacity, and DDR4-SDRAM compatibility parameters for system expansion.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 4 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 04 May 2020 |
Additional Notes
- The presence of only 1 slot confirms that memory runs in single channel mode exclusively, resulting in lower memory bandwidth compared to dual channel configurations.
- The maximum capacity limit indicates a hardware or firmware restriction that prevents the motherboard from addressing high density 8 or 16 GB modules.
- Upgrading the HP 11 Pro G5 requires a full replacement of the existing module rather than an addition because no vacant slots remain available for expansion.
- Installing a module with a frequency higher than 2400 MHz will result in downclocking to match the internal bus speed limitations of the chipset.
- The soldered nature of the processor in this series often dictates the hard cap on addressable memory space regardless of the physical slot capacity.
- Using low voltage DDR4 modules is necessary to maintain thermal efficiency within the fanless or compact chassis design typical of this product family.
