LENOVO IdeaPad 3 14ITL6 RAM upgrade specifications
LENOVO IdeaPad 3 14ITL6 supports DDR4-SDRAM memory upgrades with one SO-DIMM slot available for expansion. The laptop features on-board memory combined with one upgradeable SO-DIMM slot, achieving maximum RAM capacity of 12 GB. Compatible memory operates at 3200 MHz frequency. Upgrade specifications enable users to expand memory beyond factory configuration through the single SO-DIMM slot, subject to maximum capacity limitations. The DDR4-SDRAM form factor ensures compatibility with standard laptop memory modules.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 12 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 07 February 2023 |
Additional Notes
- The presence of soldered memory alongside a single expansion slot creates an asymmetrical dual channel configuration where only 8 GB of total system memory operates at peak bandwidth.
- Upgrading the LENOVO IdeaPad 3 14ITL6 requires matching the clock speed of the existing soldered module to prevent the system from downclocking to a lower frequency.
- Total memory capacity is limited by the fixed capacity of the internal ICs which cannot be replaced or disabled through BIOS settings.
- Standard height SO-DIMM modules are required for physical clearance as the chassis depth does not accommodate stacked or oversized heat spreaders.
- System stability depends on the installation of non-ECC unbuffered modules because the integrated memory controller lacks support for error-correcting code hardware.
- The 12 GB ceiling indicates that the motherboard firmware restricts the addressable space of the expansion slot to a maximum 8 GB module when combined with a 4 GB on-board base.
- Accessing the memory slot necessitates the removal of the entire base panel which involves navigating plastic retention clips that are prone to mechanical stress and fracture.
