LENOVO Yoga S740 RAM upgrade specifications
Lenovo Yoga S740 laptop features DDR4-SDRAM memory upgrade capability through two SO-DIMM slots. Maximum supported RAM capacity reaches 16 GB total. Compatible memory modules operate at 2666 MHz frequency. Upgrade specifications indicate SO-DIMM form factor for memory installation. Current configuration supports memory expansion options for enhanced system performance and multitasking capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 16 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 20 January 2020 |
Additional Notes
- The presence of 2 SO-DIMM slots allows for a dual-channel memory configuration which doubles the theoretical bandwidth compared to single-channel setups.
- Hardware limitations on the Lenovo Yoga S740 motherboard restrict the addressable memory capacity to 16 GB despite the physical ability to install larger capacity modules.
- Installing memory modules with higher frequency ratings will result in an automatic downclocking to match the 2666 MHz system bus limitation.
- Physical access to the memory slots requires the removal of the bottom chassis cover which may involve internal clips and captive screws.
- Syncing latency timings between both slots is necessary to maintain system stability and prevent boot failures during POST.
- The maximum capacity threshold indicates that high-density 16 GB single sticks are incompatible if used in pairs.
- Upgrading requires standard 260-pin DDR4 modules as older DDR3 or newer DDR5 variants are physically keyed differently and will not fit the slots.
