MSI Gaming GE63 Raider RGB-053 RAM upgrade specifications

MSI GE63 Raider RGB-053 MSI GE63 Raider RGB-053 MSI GE63 Raider RGB-053 MSI GE63 Raider RGB-053 MSI GE63 Raider RGB-053

The MSI GE63 Raider RGB-053 gaming laptop features DDR4-SDRAM memory upgrade specifications with two SO-DIMM slots supporting maximum RAM capacity of 32 GB. Compatible memory modules operate at 2666 MHz frequency. The GE series gaming model accepts SO-DIMM form factor upgrades, enabling users to expand total system memory from factory configurations to the specified maximum capacity of 32 GB across both available slots.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2666 MHz
Maximum RAM32 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2666 (PC4-21328)
Bandwidth21.3 GB/s
Laptop Release date12 February 2019

Additional Notes

  • Dual channel memory architecture requires matching modules in both slots to maximize memory bandwidth for high frame rate gaming.
  • The 2666 MHz frequency suggests a hardware limitation in the memory controller or chipset that prevents the use of higher speed XMP profiles.
  • Upgrading the MSI GE63 Raider RGB-053 requires removing the entire bottom chassis cover which may involve piercing a factory seal sticker to access the interior components.
  • Physical space within the 2 SO-DIMM slots restricts upgrades to standard height modules without oversized heat spreaders to ensure the case closes properly.
  • Installing 32 GB of RAM consumes all available slots and necessitates the removal of any preinstalled sticks since no additional expansion paths exist.
  • The motherboard configuration lacks soldered memory which allows for a full replacement of the volatile storage system if a module fails.
  • System stability depends on using non ECC unbuffered modules as the architecture does not support error correcting code functionality.
