MSI Gaming GL63 8SDK-483RU RAM upgrade specifications
The MSI GL63 8SDK-483RU Gaming series laptop features DDR4-SDRAM memory upgrade specifications with 2x SO-DIMM slots supporting maximum capacity of 32 GB total. Compatible memory operates at 2666 MHz frequency using SO-DIMM form factor. Upgrade specifications enable users to expand RAM capacity for enhanced system performance on the GL63 8SDK-483RU model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 13 May 2019 |
Additional Notes
- Dual channel architecture requires matching module capacities in both slots to maximize memory bus bandwidth for the MSI GL63 8SDK-483RU.
- The processor internal memory controller limits higher frequency modules to 2666 MHz through downclocking even if 3200 MHz sticks are installed.
- Reaching the maximum 32 GB capacity necessitates replacing all pre installed modules as no additional open slots exist beyond the primary 2.
- Low voltage 1.2V DDR4 modules are required to ensure thermal stability and power compatibility with the motherboard firmware.
- Physical access to the SO-DIMM slots involves removing the entire bottom chassis cover which may require breaking a factory seal depending on regional service policies.
- The 2666 MHz frequency ceiling provides a specific latency profile where modules with low CAS latency values significantly improve frame time consistency in gaming applications.
