MSI Gaming GL63 8SE-056IT RAM upgrade specifications
The MSI GL63 8SE-056IT gaming laptop features DDR4-SDRAM memory upgrade specifications with 2x SO-DIMM slots supporting maximum capacity of 32 GB RAM. The memory upgrade utilizes SO-DIMM form factor modules operating at 2666 MHz frequency. Compatible RAM modules must meet DDR4-SDRAM specifications. This Gaming GL series model supports memory configurations up to the maximum 32 GB capacity through dual slot configuration. Upgrade options accommodate standard DDR4 memory modules within specifications for enhanced system performance.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 16 January 2019 |
Additional Notes
- Dual channel memory architecture requires installing modules in pairs of identical capacity and timing to maximize memory bus bandwidth.
- The 2 slot configuration necessitates the replacement of existing modules rather than simple addition when reaching the 32 GB threshold.
- Thermal constraints within the MSI GL63 8SE-056IT chassis suggest avoiding high voltage overclocking profiles to maintain system stability under load.
- Installing memory with frequencies exceeding 2666 MHz results in automatic downclocking due to chipset limitations on the 8th generation architecture.
- Physical access to memory slots likely requires the removal of the bottom panel, which may involve breaking a factory seal depending on regional warranty policies.
- The SO-DIMM form factor restricts hardware choices to 260 pin modules, excluding standard desktop components or low power soldered variants.
- Capacity increases beyond 16 GB per slot are not supported by the motherboard firmware, creating a hard limit on total system memory scalability.
