MSI Gaming GL63 8SE-060NE RAM upgrade specifications
MSI GL63 8SE-060NE gaming laptop memory upgrade specifications indicate DDR4-SDRAM compatibility with 2x SO-DIMM slots supporting maximum RAM capacity of 32 GB total. Compatible memory operates at 2666 MHz frequency with SO-DIMM form factor. Upgrade specifications allow installation of memory modules to expand existing RAM capacity within maximum specifications for enhanced performance in the GL series gaming platform.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 14 February 2019 |
Additional Notes
- The MSI GL63 8SE-060NE contains 2 SO-DIMM slots, meaning both slots must be populated simultaneously to achieve dual-channel operation and maximum memory bandwidth; single-slot configurations will result in single-channel performance degradation of approximately 10-15% in bandwidth-intensive workloads.
- DDR4-2666 MHz specification indicates compatibility only with 8th-generation Intel Core processors; attempting to install higher-frequency DDR4 modules (3000 MHz or above) will force downclocking to 2666 MHz, negating any performance advantage and representing wasted investment on premium memory.
- The SO-DIMM form factor limits upgrade capacity to 16 GB per module maximum; reaching the 32 GB system ceiling requires installation of 2x 16 GB modules, leaving no headroom for future expansion beyond this threshold.
- Installing memory modules with higher voltage specifications (1.35V+) than the standard 1.2V DDR4 operating voltage may trigger stability issues or BIOS warnings, as the power delivery circuit in this generation is calibrated for standard voltage operation.
- Mixed-capacity configurations (such as 8 GB + 16 GB) will function but will operate both modules at the speed and timings of the slower or lower-capacity module, reducing overall system efficiency compared to matched-pair installations.
- Warranty coverage for memory upgrades typically remains valid only when using modules meeting the original equipment manufacturer's specifications; third-party modules may void hardware support claims if memory-related failures occur.
