MSI Gaming GL63 8SE-066 RAM upgrade specifications

MSI GL63 8SE-066 MSI GL63 8SE-066 MSI GL63 8SE-066 MSI GL63 8SE-066 MSI GL63 8SE-066

MSI GL63 8SE-066 Gaming series laptop features DDR4-SDRAM memory configuration with two SO-DIMM slots supporting maximum RAM capacity of 32 GB. Memory upgrade specifications include DDR4 modules operating at 2666 MHz frequency. Compatible RAM upgrades utilize SO-DIMM form factor. Current maximum memory specifications allow for dual-channel DDR4 configuration, enabling enhanced multitasking and gaming performance through expanded RAM capacity installation in available memory slots.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2666 MHz
Maximum RAM32 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2666 (PC4-21328)
Bandwidth21.3 GB/s
Laptop Release date11 March 2019

Additional Notes

  • Dual channel memory architecture requires matching module pairs to achieve full potential bus width and prevent memory controller throttling.
  • The 2666 MHz clock speed indicates the motherboard chipset limits data transfer rates even if higher rated modules are installed.
  • Upgrading the MSI GL63 8SE-066 necessitates the removal of the entire bottom chassis plate which involves breaking a factory seal sticker in certain regions.
  • Installation of 32 GB of RAM consumes all available slots and prevents further capacity expansion without discarding previous hardware.
  • The SO-DIMM form factor excludes the use of desktop sized memory components or high profile heatsinks due to vertical clearance limits within the casing.
  • Voltage requirements for DDR4-SDRAM mandate the use of 1.2V modules to ensure system stability and thermal management within the internal power delivery circuit.
  • Latency mismatches between disparate sticks will force the system to operate at the timings of the slowest module to maintain synchronization.
