MSI Gaming GL63 9SD-849UK RAM upgrade specifications

MSI GL63 9SD-849UK MSI GL63 9SD-849UK MSI GL63 9SD-849UK MSI GL63 9SD-849UK MSI GL63 9SD-849UK

The MSI GL63 9SD-849UK gaming laptop features DDR4-SDRAM memory with 2x SO-DIMM upgrade slots. Maximum RAM capacity reaches 64 GB, supporting DDR4 modules at 2666 MHz frequency. Compatible upgrades utilize SO-DIMM form factor specifications. The GL series gaming model accommodates memory expansion for enhanced multitasking and performance requirements. Specifications indicate support for dual-channel memory configurations on the GL63 9SD-849UK platform.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2666 MHz
Maximum RAM64 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2666 (PC4-21328)
Bandwidth21.3 GB/s
Laptop Release date16 August 2019

Additional Notes

  • Dual channel architecture requires matching memory modules in both slots to provide maximum memory bandwidth for the processor.
  • The 2666 MHz clock speed indicates compatibility with JEDEC standards for 9th generation Intel platforms to ensure system stability without manual BIOS adjustments.
  • Physical installation of 64 GB necessitates the use of 32 GB high density modules which are the upper limit for this chipset generation.
  • Upgrading the MSI GL63 9SD-849UK requires removing the entire bottom panel to access the SO-DIMM slots which are not located behind a dedicated service hatch.
  • The absence of soldered memory on the motherboard allows for the complete replacement of factory RAM to eliminate latency mismatches between different chip manufacturers.
  • Achieving the maximum supported capacity likely involves utilizing 1.2V modules to maintain thermal efficiency within the compact chassis.
