MSI Gaming GL65 9SD-027 RAM upgrade specifications
The MSI GL65 9SD-027 gaming laptop features DDR4-SDRAM memory upgrade specifications with 2x SO-DIMM slots supporting maximum capacity of 64 GB RAM. Compatible memory modules operate at 2666 MHz frequency and utilize SO-DIMM form factor. Upgrade options allow for expansion from the factory configuration to the maximum supported capacity. Specifications confirm DDR4 compatibility for the GL series gaming platform.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 22 July 2019 |
Additional Notes
- The dual slot configuration allows for dual channel memory architecture which significantly increases data throughput compared to single channel setups.
- Installing 64 GB of RAM in the MSI GL65 9SD-027 requires two 32 GB modules because there are no additional hidden slots on the motherboard.
- Modules with clock speeds higher than 2666 MHz will automatically downclock to match the system bus limitation preventing any realized speed gains from overclocked memory.
- Mixing modules with different latencies will force the system to operate at the timings of the slowest installed stick affecting overall platform stability.
- The SO-DIMM form factor necessitates 260 pin modules specifically designed for mobile chipsets as desktop DIMM hardware is physically incompatible.
- Physical access to the memory slots requires removal of the entire base panel which might involve breaking a factory seal depending on regional service policies.
- Voltage requirements must be strictly maintained at 1.2V to ensure compatibility with many standard DDR4 power delivery circuits on this motherboard.
