MSI Gaming GL65 9SD-226 RAM upgrade specifications
The MSI GL65 9SD-226 Gaming series laptop features DDR4-SDRAM memory specifications with 2x SO-DIMM slots for RAM upgrade capacity. Maximum compatible memory reaches 64 GB total, supporting DDR4 modules at 2666 MHz frequency. The SO-DIMM form factor enables straightforward memory expansion on this MSI Gaming GL series model, allowing users to upgrade from the factory-installed configuration to the maximum supported capacity within the available upgrade slots.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 05 February 2020 |
Additional Notes
- The MSI GL65 9SD-226 uses 2 SO-DIMM slots, meaning both slots must be populated to achieve maximum capacity. Removing existing modules triggers a dual-channel to single-channel configuration penalty, reducing effective memory bandwidth by approximately 50% until replacement modules are installed.
- DDR4-2666 MHz represents the maximum certified frequency for this platform. Modules rated above 2666 MHz will downclock to this specification automatically; purchasing higher-frequency memory provides no performance benefit and wastes capital.
- The 64 GB ceiling reflects a firmware and chipset limitation rather than physical slot constraints. Individual SO-DIMM modules exceeding 32 GB per stick exceed the platform's addressable memory range and will fail to initialize.
- SO-DIMM modules require manual removal of the bottom panel or keyboard assembly on most gaming laptops in this generation. The physical accessibility may demand technical expertise beyond standard RAM installation procedures.
- Upgrading both slots simultaneously eliminates the risk of module incompatibility or BIOS recognition failures that can occur with mixed-generation DDR4 batches. Single-slot upgrades require validation that existing modules and new memory share the same voltage specification and internal timing parameters.
- The 9th-generation Intel chipset underlying this model typically enforces strict memory profile validation at boot. Non-standard timing configurations or mismatched CAS latencies between slots can trigger boot loops, necessitating CMOS reset procedures.
