MSI Gaming GL73 8SE-029FR RAM upgrade specifications

MSI GL73 8SE-029FR MSI GL73 8SE-029FR MSI GL73 8SE-029FR MSI GL73 8SE-029FR MSI GL73 8SE-029FR

The MSI GL73 8SE-029FR gaming laptop features DDR4-SDRAM memory specifications with two SO-DIMM slots supporting maximum RAM capacity of 32 GB. Compatible memory modules operate at 2666 MHz frequency. Upgrade options allow installation of additional SO-DIMM form factor memory to achieve maximum specifications. The Gaming GL series GL73 8SE-029FR model supports memory upgrades through accessible SO-DIMM slots for expanded multitasking and performance capabilities.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2666 MHz
Maximum RAM32 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2666 (PC4-21328)
Bandwidth21.3 GB/s
Laptop Release date11 March 2019

Additional Notes

  • Dual channel architecture requires matching memory module densities across both slots to achieve maximum theoretical memory bandwidth for the MSI GL73 8SE-029FR.
  • The hardware architecture utilizes 260 pin physical interfaces which are incompatible with desktop DIMM modules or older DDR3 layouts.
  • Integrated memory controllers will downclock higher frequency modules to the 2666 MHz limit established by the system chipset.
  • Accessing the SO-DIMM slots involves removing the base chassis cover which may require breaking a factory seal depending on regional warranty policies.
  • Capacity expansion beyond 32 GB is unsupported by the BIOS and may result in a failure to boot or system instability.
  • The use of high density 16 GB modules in both slots is necessary to reach the maximum ceiling because no soldered memory exists on the motherboard.
  • Latency timings should be matched between existing and new modules to prevent the system from defaulting to the slowest shared JEDEC profile.
