MSI Gaming GL76 12UEK-047UK Pulse RAM upgrade specifications
MSI GL76 12UEK-047UK Pulse gaming laptop supports DDR4-SDRAM memory upgrade via 2x SO-DIMM slots. Maximum compatible RAM capacity reaches 64 GB total. Specifications include 3200 MHz frequency support and SO-DIMM form factor. The gaming series device accommodates standard DDR4 memory modules for performance enhancement beyond factory-installed configuration.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 22 December 2021 |
Additional Notes
- The dual channel architecture requires matching module pairs to achieve full memory bandwidth and prevents single channel performance throttles during heavy gaming or rendering tasks.
- Utilizing 3200 MHz modules ensures the internal memory controller operates at 1:1 gear mode for optimal latency without downclocking issues.
- System expansion to 64 GB necessitates the complete replacement of existing factory modules because the MSI GL76 12UEK-047UK Pulse lacks additional vacant slots for incremental updates.
- Standard density 1.2V SO-DIMM modules prevent thermal overhead within the chassis and maintain compatibility with the fixed voltage regulator of the motherboard.
- Installation of high capacity 32 GB sticks in each slot occupies the total addressable physical space allowed by the CPU architecture.
- Replacement of memory requires the removal of the bottom base cover which involves breaking a factory seal if present in specific regions.
- The choice of DDR4 technology limits the maximum data transfer rates compared to newer DDR5 platforms but offers significantly lower CAS latency for sensitive applications.
