MSI Gaming GP62MVR 7RFX Leopard Pro RAM upgrade specifications
The MSI GP62MVR 7RFX Leopard Pro gaming laptop features two SO-DIMM memory slots supporting DDR4-SDRAM upgrade modules. The system supports maximum RAM capacity of 32 GB total, with compatible memory operating at 2400 MHz frequency. Each slot accepts SO-DIMM form factor modules, enabling users to upgrade from the original configuration up to the specified maximum capacity. Specifications confirm DDR4 memory compatibility for this MSI Gaming GP series model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 20 March 2018 |
Additional Notes
- Dual channel memory architecture is only achievable when both slots are occupied by identical capacities to maximize bandwidth for the integrated graphics and CPU communication.
- The MSI GP62MVR 7RFX Leopard Pro utilizes a SODIMM form factor which restricts upgrade options to small outline modules and precludes the use of standard desktop DIMM hardware.
- Installing memory modules with frequencies exceeding 2400 MHz results in automatic downclocking to the motherboard limit of the chipset.
- The ceiling of 32 GB requires the utilization of two 16 GB modules as the firmware does not support high density 32 GB single sticks.
- Accessing the memory slots involves removing the base panel which may require piercing a factory seal sticker and potentially impacting local warranty terms depending on regional consumer laws.
- Thermal constraints within the chassis suggest that memory modules with tall integrated heat spreaders will interfere with the bottom cover clearance.
- Latency performance is tied to the JEDEC profile of the memory because the BIOS typically lacks XMP support for manual timing adjustments.
