MSI Gaming GE75 9SF-836FR Raider RAM upgrade specifications
MSI GE75 9SF-836FR Raider gaming laptop features DDR4-SDRAM memory upgrade specifications. The system contains two SO-DIMM slots for memory expansion. Compatible RAM modules operate at 2666 MHz frequency. Maximum RAM capacity supported reaches 64 GB total. Current specifications allow memory upgrades utilizing standard SO-DIMM form factor modules. Compatibility requires DDR4-SDRAM specifications matching the GE75 9SF-836FR Raider series requirements for optimal performance.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 31 August 2019 |
Additional Notes
- The dual slot configuration requires removing the factory modules to reach the maximum capacity because there are no available empty expansion bays.
- Operating 2 modules of identical capacity is necessary to enable dual channel memory mode and maximize the processor integrated memory controller efficiency.
- Installing modules with frequencies higher than 2666 MHz results in an automatic clock speed downshift to match the motherboard firmware limitations.
- High density 32 GB modules must be used in each SO-DIMM slot to achieve the 64 GB limit supported by the MSI GE75 9SF-836FR Raider architecture.
- The physical SO-DIMM footprint limits hardware cooling to passive heat spreaders due to the tight vertical clearance within the chassis base.
- Non ECC unbuffered memory is required for compatibility as the system chipset does not support error correcting code functionality.
- Accessing the memory slots necessitates the removal of the entire bottom panel which may involve piercing a factory seal sticker in certain regions.
