MSI Katana 12UE-286FR RAM upgrade specifications
The MSI Katana GF76 12UE-286FR laptop features DDR4-SDRAM memory with 2x SO-DIMM slots for RAM upgrades. The upgrade specifications indicate a maximum compatible capacity of 64 GB total memory, supporting DDR4 modules at 3200 MHz frequency. The SO-DIMM form factor specifications define the physical and electrical requirements for compatible memory modules in this MSI gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 28 April 2022 |
Additional Notes
- Dual channel memory architecture requires installing modules in identical pairs to achieve maximum data throughput and prevent memory bus bottlenecks.
- The MSI Katana 12UE-286FR utilizes a specific motherboard layout where reaching the 64 GB limit necessitates replacing both factory pre installed modules simultaneously.
- Upgrading should prioritize 1.2V JEDEC compliant sticks to ensure system stability because the firmware often lacks XMP overclocking profile support for voltage adjustments.
- Physical access to the SO-DIMM slots requires the removal of the entire bottom chassis cover which involves penetrating a factory seal sticker in certain regional jurisdictions.
- Mixing modules with different internal timings will force the memory controller to downclock to the slowest common latency values regardless of the rated frequency.
- The integrated memory controller on the CPU dictates the actual effective bandwidth even if modules with higher rated speeds are installed into the slots.
