MSI Modern 15 A11M-045XES RAM upgrade specifications
The MSI Modern 15 A11M-045XES laptop features DDR4-SDRAM memory with two SO-DIMM slots supporting maximum RAM capacity of 64 GB. Compatible upgrade specifications include 3200 MHz frequency DDR4 modules. The laptop's memory slots accommodate standard SO-DIMM form factor upgrades, enabling users to expand from the original configuration to the maximum 64 GB capacity through compatible memory modules.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 13 September 2020 |
Additional Notes
- The presence of 2 physical SO-DIMM slots allows for a dual-channel memory configuration which doubles the theoretical bandwidth between the processor and the system RAM.
- The MSI Modern 15 A11M-045XES supports high-density 32 GB modules per slot to reach the maximum capacity of 64 GB for memory-intensive virtualization or video rendering tasks.
- Systems utilizing 3200 MHz DDR4 typically operate at 1.2V meaning that low-voltage modules are required to ensure stability and maintain thermal efficiency within the chassis.
- Upgrading memory requires the removal of the entire bottom base cover which may involve piercing a factory seal sticker depending on regional warranty policies.
- Optimal integrated graphics performance relies on installing matched pairs of RAM to ensure the GPU has sufficient data throughput for 3D applications.
- The internal layout requires the use of standard height SO-DIMM modules as oversized heat spreaders will interfere with the physical closure of the laptop casing.
