MSI Modern 15 A11M-211AU RAM upgrade specifications
MSI Modern 15 A11M-211AU laptop supports DDR4-SDRAM memory upgrade specifications. The device contains 2x SO-DIMM slots for RAM installation. Maximum compatible memory capacity reaches 64 GB. Memory modules operate at 3200 MHz frequency. SO-DIMM form factor specifications apply to all compatible RAM upgrades. These upgrade specifications enable users to expand the laptop's memory capacity for enhanced multitasking and performance capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 19 January 2021 |
Additional Notes
- Full utilization of the 64 GB capacity on the MSI Modern 15 A11M-211AU requires the physical replacement of both existing modules with 32 GB sticks.
- The dual slot configuration supports interleaved memory mode which significantly improves integrated graphics performance compared to single channel setups.
- Integrating modules with speeds higher than 3200 MHz will result in automatic downclocking to match the system bus limitations.
- The SO-DIMM form factor necessitates 260 pin modules specifically designed for mobile chipsets rather than desktop DIMM hardware.
- Mixed latency timings between mismatched brands will force the motherboard to operate at the secondary timings of the slower module.
- Accessing the memory slots requires removal of the bottom chassis cover which involves penetrating factory seals and potentially impacting regional warranty terms.
- Voltage requirements for DDR4 modules must remain at 1.2V to ensure stability and prevent thermal throttling within the compact frame.
