MSI Prestige 15 A10SC-011 RAM upgrade specifications
MSI Prestige 15 A10SC-011 laptop supports DDR4-SDRAM memory upgrade through 2x SO-DIMM slots. Maximum RAM capacity reaches 64 GB with DDR4-2666 MHz specifications. Compatible memory upgrades utilize SO-DIMM form factor modules for this model. Existing memory configurations can be expanded to achieve maximum capacity through replacement of standard modules in designated slots.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 28 August 2019 |
Additional Notes
- The MSI Prestige 15 A10SC-011 operates with DDR4 memory at 2666 MHz, which represents a potential performance ceiling below the 3200 MHz standard of modern DDR4 platforms. Memory upgrade modules rated at higher frequencies will downclock to 2666 MHz, negating cost premiums for faster variants.
- Dual SO-DIMM slots limit total capacity expansion to 64 GB maximum. This constraint persists regardless of individual module density improvements, as the motherboard cannot accept a third or fourth memory channel.
- Both memory slots must be populated identically for optimal dual-channel performance. Mismatched module capacities or speeds will force the system into single-channel mode or apply the lower specification to both modules, degrading bandwidth by approximately 50 percent.
- SO-DIMM form factor is non-upgradeable in terms of physical geometry; desktop DDR4 UDIMM modules are incompatible with this ultraportable form factor and cannot be adapted with passive converters.
- Warranty preservation typically requires purchasing memory modules from approved vendors. Third-party RAM upgrades may trigger exclusions in hardware support coverage depending on MSI service policies at point of upgrade.
- The 10th-generation Intel processor architecture (indicated by "A10" in the model designation) maintains forward compatibility with DDR4-3200 specifications, but factory configuration at 2666 MHz suggests conservative thermal and power budgeting in this chassis class.
