MSI Prestige P65 8SF-250FR Creator RAM upgrade specifications
The MSI Prestige P series P65 8SF-250FR Creator laptop features DDR4-SDRAM memory upgrade specifications with 2x SO-DIMM slots supporting maximum capacity of 32 GB total. Compatible memory modules operate at 2666 MHz frequency using SO-DIMM form factor. Upgrade specifications enable expansion of existing RAM capacity through available slots, with DDR4 memory technology providing standard performance characteristics for creator-class computing applications.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 07 June 2019 |
Additional Notes
- The MSI Prestige P65 8SF-250FR Creator contains 2 SO-DIMM slots, meaning only one memory module can be added without removing the factory-installed module. Dual-channel operation requires populated pairs, so single-stick upgrades will disable memory interleaving until the second slot is also populated.
- DDR4-2666 MHz specification indicates the motherboard controller locks memory to this frequency regardless of module rated speed. Installing faster DDR4 modules (3000+ MHz) will downclock to 2666 MHz, eliminating any performance gain from premium memory purchases.
- The 32 GB ceiling (16 GB per slot maximum) means full capacity requires 2x16 GB SO-DIMM modules. Upgrading from factory configuration to 32 GB requires replacing both modules rather than adding a single larger stick, as SO-DIMM form factor limits individual module density on this generation platform.
- SO-DIMM slots occupy minimal motherboard real estate beneath the keyboard deck on mobile workstations. Accessing these slots typically requires keyboard removal and may mandate dust filter cleaning during the process, extending installation time beyond desktop RAM upgrades.
- DDR4-2666 bandwidth delivers approximately 21 GB/s aggregate throughput. Dual-channel configuration reaches this peak only when both slots are populated; single-channel operation after partial upgrade halves available memory bandwidth until the second module is installed.
- Factory memory often features soldered or non-removable configurations on some Creator-series laptops. Verifying whether installed RAM uses standard SO-DIMM sockets before purchasing replacement modules prevents incompatibility with non-upgradeable memory designs.
