MSI Prestige PS63 8RC-029FR Modern RAM upgrade specifications

MSI PS63 8RC-029FR Modern MSI PS63 8RC-029FR Modern MSI PS63 8RC-029FR Modern MSI PS63 8RC-029FR Modern MSI PS63 8RC-029FR Modern

MSI Prestige PS63 8RC-029FR Modern laptop RAM upgrade specifications indicate DDR4-SDRAM memory compatibility with 2x SO-DIMM slots. Maximum memory capacity reaches 32 GB total. Compatible upgrade modules operate at 2400 MHz frequency using SO-DIMM form factor. Specifications detail memory configuration slots available for RAM expansion on this MSI Prestige PS series model.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2400 MHz
Maximum RAM32 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2400 (PC4-19200)
Bandwidth19.2 GB/s
Laptop Release date10 April 2019

Additional Notes

  • Dual channel architecture requires matching memory modules to reach peak data throughput and eliminate memory bus bottlenecks.
  • The MSI PS63 8RC-029FR Modern utilizes a standard voltage profile which necessitates the use of DDR4 non ECC unbuffered modules for system stability.
  • Installing RAM modules with clocks higher than 2400 MHz results in automatic downclocking to the controller limit which increases latency timings.
  • Upgrading beyond the 32 GB threshold causes a failure to POST due to the hardware limitations of the processor memory controller.
  • Accessing the SO-DIMM slots requires the removal of the entire base cover and the potential breaking of a factory seal sticker which varies by regional warranty policy.
  • The presence of 2 slots means that reaching the capacity limit necessitates replacing both existing modules if the factory configuration occupies both sockets.
  • Heat dissipation for secondary memory sticks depends on passive airflow within the chassis as no dedicated heat spreaders cover the SO-DIMM area.
