MSI Stealth A11UEK-058FR RAM upgrade specifications
The MSI Stealth 15M A11UEK-058FR laptop supports DDR4-SDRAM memory upgrades through two SO-DIMM slots. Current specifications allow maximum RAM capacity of 64 GB total, with compatible modules operating at 3200 MHz frequency. Memory upgrade options accommodate SO-DIMM form factor modules, enabling users to expand system memory beyond factory configuration for enhanced multitasking and application performance capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 01 January 2021 |
Additional Notes
- Dual channel mode is only achievable when both slots contain identical module capacities and timings to maximize memory bandwidth.
- The MSI Stealth A11UEK-058FR utilizes a flip motherboard design that requires complete removal of the internal chassis components to access the memory slots.
- Upgrading beyond the factory configuration requires low profile modules to ensure clearance within the thin chassis profile.
- Installing high performance modules with XMP profiles may result in memory downclocking to JEDEC standards if the BIOS does not support advanced voltage adjustments.
- Populating both slots with 32 GB modules to reach the 64 GB limit increases thermal density near the CPU and GPU heat pipes.
- The integrated memory controller on the processor dictates the final stable frequency regardless of the rated speed on the replacement sticks.
- Physical access to the SO-DIMM slots involves breaking a factory seal which affects warranty terms in specific regional jurisdictions.
