MSI Workstation WE62 7RI-2002FR RAM upgrade specifications

MSI WE62 7RI-2002FR MSI WE62 7RI-2002FR MSI WE62 7RI-2002FR MSI WE62 7RI-2002FR MSI WE62 7RI-2002FR

The MSI WE62 7RI-2002FR workstation features DDR4-SDRAM memory upgrade capabilities with two SO-DIMM slots supporting a maximum capacity of 32 GB. Compatible memory modules operate at 2400 MHz frequency and utilize the SO-DIMM form factor. Specifications enable RAM upgrades from standard configurations to the maximum supported capacity of 32 GB across both available slots on the MSI WE62 series platform.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2400 MHz
Maximum RAM32 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2400 (PC4-19200)
Bandwidth19.2 GB/s
Laptop Release date05 January 2018

Additional Notes

  • The dual-channel architecture requires installing two identical modules to achieve peak memory bandwidth and prevent system throughput bottlenecks.
  • Upgrading the MSI WE62 7RI-2002FR to the 32 GB threshold necessitates the replacement of both factory modules since no additional expansion slots exist.
  • Installing modules with frequencies higher than 2400 MHz results in automatic downclocking to match the integrated memory controller hardware limitations.
  • The SO-DIMM form factor restricts hardware selection to 260-pin laptop modules and excludes full-sized desktop components.
  • Accessing the internal slots typically requires the removal of the entire base panel which may involve piercing a factory seal sticker in certain regions.
  • Latency disparities between mismatched sticks will force the system to operate at the timings of the slowest installed module.
  • The 32 GB maximum capacity is dictated by the chipset architecture and cannot be surpassed even if higher density modules are physically compatible.
