ACER Nitro AN515-45-R6Y2 RAM upgrade specifications

ACER AN515-45-R6Y2 ACER AN515-45-R6Y2 ACER AN515-45-R6Y2 ACER AN515-45-R6Y2 ACER AN515-45-R6Y2

The ACER Nitro 5 Series AN515-45-R6Y2 laptop features DDR4-SDRAM memory with upgrade capacity supported through two SO-DIMM slots. Maximum RAM specifications allow up to 32 GB total memory capacity. Compatible memory modules operate at 3200 MHz frequency. The SO-DIMM form factor designates the memory upgrade specifications for this Nitro 5 Series model.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency3200 MHz
Maximum RAM32 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-3200 (PC4-25600)
Bandwidth25.6 GB/s
Laptop Release date12 March 2021

Additional Notes

  • Dual channel architecture requires matching module pairs to achieve full memory bandwidth and reduce latency in high demand applications.
  • The ACER Nitro AN515-45-R6Y2 firmware limits clock speeds to 3200 MHz regardless of whether higher rated modules are installed.
  • Internal expansion requires the removal of the bottom chassis cover which may involve piercing factory seals depending on regional warranty policies.
  • Total memory capacity is capped at 32 GB due to motherboard chipset limitations preventing the use of 32 GB single sticks in each slot.
  • The SO-DIMM form factor necessitates 260 pin modules specifically designed for mobile platforms rather than desktop counterparts.
  • Populating both slots allows the integrated graphics processor to access wider data paths for improved visual rendering speeds.
  • Mixing modules with different CAS latencies forces the system to default to the slowest common timing profile available.
