ACER TravelMate P259-G2-M-534A RAM upgrade specifications
The Acer TravelMate P2 series model P259-G2-M-534A supports DDR4-SDRAM memory upgrades through two SO-DIMM slots. Maximum supported capacity reaches 32 GB total. Compatible memory modules operate at 2133 MHz frequency and utilize SO-DIMM form factor. Memory upgrade specifications enable expansion of system RAM capacity for enhanced multitasking performance on this laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2133 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2133 (PC4-17064) |
| Bandwidth | 17.1 GB/s |
| Laptop Release date | 20 April 2017 |
Additional Notes
- The presence of 2 physical SO DIMM slots allows for dual channel memory configurations which doubles the theoretical bandwidth between the controller and the system memory.
- Upgrading the ACER TravelMate P259-G2-M-534A beyond 32 GB is prevented by the hardware abstraction layer and memory controller limitations regardless of individual module density.
- Installing modules with frequencies higher than 2133 MHz results in automatic downclocking to the bus speed defined by the chipset to maintain system stability.
- Internal access for memory replacement requires the removal of the bottom chassis panel which may involve piercing factory seals depending on regional warranty policies.
- Mismatched latency timings between 2 different RAM modules force the system to operate at the slower common denominator to prevent data corruption or boot failure.
- Symmetric memory population with 2 identical capacity sticks ensures consistent performance for integrated graphics tasks that rely heavily on shared system memory.
