ASUS ProArt StudioBook W700G1T-AV011R RAM upgrade specifications
The ASUS ProArt StudioBook Pro 17 W700G1T-AV011R workstation features DDR4-SDRAM memory upgrade capabilities with two SO-DIMM slots supporting maximum RAM capacity of 64 GB. Memory specifications include 2666 MHz frequency and SO-DIMM form factor. Compatible memory upgrades enable expansion from the factory configuration to the maximum supported capacity of 64 GB total, accommodating professional computing and creative applications on the ProArt StudioBook Pro 17 series.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 04 March 2020 |
Additional Notes
- The dual-slot configuration necessitates the removal of existing modules to reach the 64 GB maximum capacity since no vacant slots remain for expansion.
- Operating in a dual-channel environment requires matching pair kits to ensure symmetrical memory bandwidth for rendering tasks on the ASUS ProArt StudioBook W700G1T-AV011R.
- Installing memory modules with speeds exceeding 2666 MHz results in automatic downclocking to remain compatible with the integrated memory controller limits.
- The SO-DIMM form factor restricts motherboard compatibility to 260-pin modules and excludes the use of desktop-grade DIMM hardware.
- Latency performance depends on the CAS latency rating of the installed hardware as the system does not support XMP profiles for manual timing adjustments.
- High-density 32 GB modules are required in both slots to achieve the peak supported memory overhead for professional creative workflows.
- Heat dissipation within the compact chassis remains a factor when utilizing high-capacity modules during sustained computational loads.
