ASUS ROG GV601RM-M6007W RAM upgrade specifications
The ASUS ROG Flow X16 GV601RM-M6007W features DDR5-SDRAM memory upgrade capabilities with 2x SO-DIMM slots supporting maximum capacity of 64 GB RAM. Compatible memory modules operate at 4800 MHz frequency specifications. Existing memory can be replaced or expanded through available SO-DIMM slots to achieve maximum RAM capacity. Upgrade specifications indicate DDR5 technology compatibility for enhanced performance on the GV601RM-M6007W laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 13 July 2022 |
Additional Notes
- The presence of 2 SO-DIMM slots allows for a dual-channel memory configuration which improves bandwidth for integrated graphics and CPU-intensive tasks compared to single-channel arrangements.
- Upgrading the ASUS GV601RM-M6007W to the 64 GB maximum requires the installation of 2 matched 32 GB modules while demanding the removal of all pre-installed factory memory.
- The DDR5 architecture incorporates on-die ECC and internal power management circuits which shift voltage regulation responsibilities away from the motherboard to the RAM module itself.
- Operating at 4800 MHz utilizes the standard JEDEC baseline for this generation but remains sensitive to CAS latency timings when mixing modules from different manufacturers.
- The physical SO-DIMM interface necessitates a technician to verify that high-capacity 32 GB sticks do not exceed the standard component height to ensure the bottom chassis panel seats correctly without applying pressure to the motherboard.
- Future-proofing via 64 GB of total capacity provides sufficient overhead for 4K video editing and virtual machine hosting without triggering disk-based swap file usage.
