ASUS ROG GV601RM-M6074W RAM upgrade specifications
ASUS ROG Flow X16 GV601RM-M6074W compatible RAM upgrade specifications include DDR5-SDRAM memory modules in SO-DIMM form factor. The laptop features 2 memory slots supporting maximum RAM capacity of 64 GB total. Compatible memory operates at 4800 MHz frequency. Upgrade configurations allow installation of matched pairs to achieve maximum capacity specifications. Memory modules must be DDR5-SDRAM SO-DIMM type for compatibility with this portable workstation model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 30 May 2022 |
Additional Notes
- The ASUS ROG GV601RM-M6074W uses SO-DIMM slots, restricting upgrades to laptop-specific memory modules rather than standard desktop DDR5 variants. Desktop DDR5 UDIMMs are physically incompatible with this form factor and will not fit.
- DDR5-4800 MHz memory operates at mobile-grade specifications. Aftermarket SO-DIMM modules rated for higher frequencies (5600 MHz or beyond) will downclock to 4800 MHz on this platform, eliminating any speed advantage from premium modules.
- The 2-slot configuration limits total capacity expansion to 64 GB maximum. Upgrading both slots to 32 GB modules represents the ceiling; single-slot upgrades cannot exceed 32 GB per module within the SO-DIMM DDR5 market.
- SO-DIMM DDR5 supply remains constrained relative to UDIMM availability. Module selection and pricing vary significantly by region and retailer, potentially extending lead times for specific capacity or speed combinations.
- Populating both memory slots simultaneously may trigger minor thermal effects in the compact chassis design typical of mobile workstations. Heat dissipation from memory modules is adequate but not redundant.
- Memory upgrade procedures on this model typically require removal of the bottom panel and disconnection of the battery connector. Non-invasive access to SO-DIMM slots is unlikely; standard warranty terms usually permit this maintenance without voiding coverage when performed correctly.
